Replaceable 7.4V 22.2Wh lithium polymer battery ,Working time about 10 hours Receive and display RS485 data sent from controlling device Pelco-D/P、Samsung、Panasonic、Lilin、Yaan more than 30 protocols Send PAL/NTSC format a variety of graphic video test signalġ2V/2A output interface：Circular diameter 4mm，internal needle 1.6mm Supports “fit screen”“1X”“2X”“4X” Four multiples ,screen shot, recording（h.264) Video display brightness, contrast, color saturation is adjustable 802.3at 25.5W max，PD actual power measurement When recharging with the self-contained POE power charging injector, the injector data in port can be also connected to the Internet at the same time.ġ0M/100M/1G Ethernet link；Ethernet loop detection；DHCP client and server ；Įthernet traffic flow monitor* Data link quality monitor*ĭiscover devices，real-time video，camera configuration，PTZ test，inter-subnet discovery of ONVIF deviceįull-screen preview, zoom in the preview(Fit screen,1x，2x,4x)，screen shot and video recording （Meta data ）ĭual-port RJ45 Ethernet 1Gbps，bridge mode supported；Īccept power from PSE ,802.3at Supply voltage monitor ◇ Do not use non-standard POE power supply and non-standard POE injector to recharge. Otherwise it may damage the tester. And the tester may automatically reset and even cause malfunction when battery runs out. ◇ If DC12V or PSE power output is applied when recharging, the output consumption can be higher than the input power supply, in that case, the battery can’t be recharged and even cause discharging. However, it’ll take a little longer to recharge when the tester is power-on.
◇ Recharging is available when tester is power-on and off. When battery is fully charged, the charge indicator will turn off. ◇ It will take 3~4 hours to recharging a fully run-out battery.
When the yellow light of port 2 and the charge indicator turns on, the tester starts to recharge the battery. ◇ Connect POE injector output port to tester port 2 via a RJ45 cable.
